62-11785 3–14
3.10 DATA RECORDER - Continued
3.10.3 Data Downloading
The data within the DataLink data recorder can be downloaded using either the TRU-Tech/TRU-View program with
a PC-USB service cable connected to the USB interface port or with a Data Transfer USB memory device (refer to
Section 5.3.3).
3.10.4 DataLink Data Recorder Power-Up
The DataLink data recorder records data the entire time the START/RUN - OFF switch is in the START/RUN posi-
tion. A Configuration exists which allows the user to select whether an additional 8 hours of sensor data be
recorded after the switch is placed in the OFF position, or to stop recording at the same time the switch is placed in
the OFF position. The factory setting is to record the additional 8 hours so the temperatures will be recorded during
the unloading or other times when it may be necessary to turn the unit off. (Refer to Section 5.2.3.)
1. With the system powered up (START/RUN-OFF switch in the START/RUN position) or in PC Mode press
the MENU key until DATA RECORDER is displayed.
2. Press the DATA RECORDER soft key to display the sub menus.
3. The Data Recorder screen will display with a 15 second timeout. Press the ▲ or ▼ key to scroll through the
available sub menus. With the desired sub-menu highlighted, press the “=” Key to enter the menu.
START/STOP ELECTRIC COOL
Viewing Menu Soft Key
LANGUAGE
DATA
EXIT
Selections
Press Menu Key to Scroll
RECORDER
2
1
DATA RECORDER (1 of 5)
MARK TRIP START
BACK
EXIT
PRINT TO SCREEN
PRINT TO PRINTER
SCREEN SETUP
PRINTER SETUP
To Next Page
