Page #223 background image
7–85 62-11785
24102 SENSOR INPUT VOLTAGE HIGH CCB1
• ACTIVATION: The Voltage Supply for the Sensors on the CCB1 is above High voltage limit 5.5V.
• UNIT CONTROL: Alarm Only.
• RESET CONDITION: The Voltage Supply for Sensors on CCB1 is below the High voltage limit 5.5V.
NOTE: Follow the steps below until a problem is found. Once a repair or correction has been made, clear the
alarm(s). (See Note 1 in Notes Section.) Operate the unit through the appropriate modes to see if any active
alarm occurs. Continue with the steps below as necessary.
CORRECTIVE ACTIONS:
Check for power at CCB1 - Check power at pins 14 and 26. Verify battery power.
24200 NO COMM FROM MICRO TO CCB2
• ACTIVATION: If alarm 21100 NO COMM FROM ANY BOARD TO MAIN MICRO is not active, and no
sync responses have been received from the CCB2 Module for 10 seconds.
• UNIT CONTROL: Required Shutdown. If alarm remains active for 2 minutes issue a shutdown command
to all modules except the display.
• RESET CONDITION: Sync response received from the CCB2 Module in the past 10 seconds, alarm
reset or alarm may be manually reset by turning the unit off, then back on again.
NOTE: Follow the steps below until a problem is found. Once a repair or correction has been made, clear the
alarm(s). (See Note 1 in Notes Section.) Operate the unit through the appropriate modes to see if any active
alarm occurs. Continue with the steps below as necessary.
CORRECTIVE ACTIONS:
1. Check CCB2 status indicator. Refer to Section 2.5.4.
2. Check Fuse F9
a. Visually check fuse. Verify correct fuse, check fuse holder for damage, see Figure 2.4. Replace
fuse as required. Clear alarms, restart and check for repeat alarm(s).
b. Check voltage. Check voltage through fuse, if fuse is blown, replace it.
c. Check wiring. Verify there is no physical damage to harness, and no damage, moisture, or
corrosion in connectors.
3. Check wires from CCB1 - Check wiring from pins 6 and 29. Verify there is no physical damage to har-
ness, and no damage, moisture, or corrosion in connectors.
