The system may be configured to display the sensor reading in the Unit Data and to record the sensor reading in
the DataLink data recorder. A user specified name may be configured for each sensor. This name will be displayed,
rather than the default Remote Sensor #1, #2 or #3, name in the unit data list.
2.6.4 Remote Panel
The unit may be fitted with an optional remote control panel. The remote panel, which is very similar to the display
module, displays compartment setpoints, compartment temperatures and operating modes (heat, cool or defrost).
The setpoint may be modified and the unit may be started and stopped using the remote panel.
This compact remote panel can be mounted to suit the individual operator’s preferences - on the front bulkhead, or
in the compartment (including in the wall itself). Remote Panel keys, soft keys and alarm indicators are in the same
locations as the main APX display module.
2.7 COMPRESSOR DATA
2.8 REFRIGERATION SYSTEM DATA
2.9 ELECTRICAL DATA
Unit Specification
Compressor Part Number 18-10151-00
Type Hermetic Scroll
Displacement 8.81 Cubic Inches Per Revolution
Weight 88.5 lbs (40.14 kg) Dry
Oil Charge 60 ounces (1.77 liters) (Service Replacement)
Approved Compressor Oil Uniqema Emkarate RL-32-3MAF Carrier P/N 46-00025-04
Unit Specification
Defrost Air Switch (DAS) Initiates Defrost: 1.40 ± .07 inch (35 ± 1.8 mm)
Defrost Timer 1.5h, 3h, 6h, or 12 hours
Evaporator High Temperature Switch Opens, on a temperature rise, at 130 ± 5°F (55 ± 2.8°C)
Closes, on a temperature fall, at 100 ± 7°F (37.8 ± 3.9°C)
Liquid Injection Valve (LIV) Energized (opened) at Compressor Discharge Temperature (CDT)
Sensor readings above 275°F (135°C)
May be pulsing (opened & closed) between Compressor Discharge
Temperature (CDT) Sensor reading of 255°F & 275°F (124°C & 135°C)
De-energized (closed) at (CDT reading below 124°C (255°F)
Fusible Plug Melting Point 430°F (221°C)
High Pressure Switch (HPS) Opens, on pressure rise, at: 495 ± 10 psig (34.1 ± 3 bar)
Closes, on pressure fall, at: 380 ± 10 psig (26.2 ± 3 bar)
Unit Weight, Less Battery 1,095 lbs (497 kg)
Battery 50 pounds (23 kg)
Refrigerant Charge Refer to Table 2–1
Unit Specification Detail
Compressor Motor
Rated Load Amps 14.2 amps @ 460 VAC
Locked Rotor Amps 99.0 amps @ 460 VAC
Winding Resistance Approximately 1.63 ohms, phase to phase
