8.8.14 Temperature Sensor Checkout
An accurate ohmmeter must be used to check resistance values shown in Table 8–3 or Table 8–4.
Due to variations and inaccuracies in ohmmeters, thermometers or other test equipment, a reading within 2% of
the chart value would indicate a good sensor. If a sensor is bad, the resistance reading will usually be much higher
or lower than the resistance values given in the tables.
Two preferred methods of determining the actual test temperature at the sensor, is an ice bath at 32°F (0°C) or a
calibrated temperature tester.
Table 8–3 Sensor Resistance
Sensors AAT, RAT, SAT, ENCT, DTT, CST, EVOT, REMSN 1, 2, & 3
°F °C Ohms °F °C Ohms °F °C Ohms °F °C Ohms
-40 -40 336,500 18 -7.8 49,060 76 24.4 10,250 134 56.7 2,809
-38 -38.9 312,600 20 -6.7 46,230 78 25.6 9,760 136 57.8 2,697
-36 -37.8 290,600 22 -5.6 43,580 80 26.7 9,299 138 58.9 2,590
-34 -36.7 270,300 24 -4.4 41,100 82 27.8 8,862 140 60.0 2,488
-32 -35.6 251,500 26 -3.3 38,780 84 28.9 8,449 142 61.1 2,390
-30 -34.4 234,200 28 -2.2 36,600 86 30.0 8,057 144 62.2 2,297
-28 -33.3 218,200 30 -1.1 34,560 88 31.1 7,686 146 63.3 2,208
-26 -32.2 203,400 32 0 32,650 90 32.2 7,334 148 64.4 2,124
-24 -31.1 189,700 34 1.1 30,850 92 33.3 7,000 150 65.6 2,042
-22 -30 177,000 36 2.2 29,170 94 34.4 6,684 155 68.3 1,855
-20 -28.9 165,200 38 3.3 27,590 96 35.6 6,384 160 71.1 1,687
-18 -27.8 154,300 40 4.4 26,100 98 36.7 6,099 165 73.9 1,537
-16 -26.7 144,200 42 5.5 24,700 100 37.8 5,828 170 76.7 1,402
-14 -25.6 134,800 44 6.6 23,390 102 38.9 5,571 175 79.4 1,281
-12 -24.4 126,100 46 7.7 22,160 104 40.0 5,327 180 82.2 1,171
-10 -23.3 118,100 48 8.9 20,990 106 41.1 5,095 185 85.0 1,072
-8 -22.2 110,500 50 10 19,900 108 42.2 4,874 190 87.8 983
-6 -21.1 103,600 52 11.1 18,870 110 43.3 4,665 195 90.6 902
-4 -20 97,070 54 12.2 17,900 112 44.4 4,465 200 93.3 829
-2 -18.9 91,030 56 13.3 16,980 114 45.5 4,275 205 96.1 762
0 -17.8 85,400 58 14.4 16,120 116 46.7 4,095 210 98.9 702
2 -16.7 80,160 60 15.5 15,310 118 47.8 3,923 215 101.7 647
4 -15.6 75,270 62 16.6 14,540 120 48.9 3,759 220 104.4 598
6 -14.4 70,720 64 17.7 13,820 122 50. 3,603 225 107.2 553
8 -13.3 66,460 66 18.9 13,130 124 51.1 3,454 230 110.0 511
10 -12.2 62,500 68 20.0 12,490 126 52.2 3,313 235 112.8 473
12 -11.1 58,790 70 21.1 11,880 128 53.3 3,177 240 115.6 438
14 -10.0 55,330 72 22.2 11,310 130 54.4 3,049 245 118.3 406
16 -8.9 52,090 74 23.3 10,760 132 55.6 2,926 250 121.1 378
