2.2 Key Panel and Operation
Functions of the keys
During Weighing
Key
Press Once and Release Press and Hold for About 3 Seconds
[POWER]
Switches between the operation and standby
modes.
Exits the application function and returns to
the mass display.
[CAL]
Enters span calibration or menu item
selection. (*1)
Displays the last menu item that was set.
(Last menu recall)
[O/T] Tares the balance. (Displays zero.)(*2) (*5) Displays the Pretare value.
[UNIT]
Changes the weighing unit or selects
specific gravity measurement. (*3)
Switches between the 1d and 10d
display. (*4)
[PRINT]
Sends the displayed value to a peripheral
device.
Sends the date and time to a peripheral
device.
＊1 This key is used to set values when percent (%), number (PCS), solid specific gravity
(??d), or liquid specific gravity (▼d) are displayed.
＊2 When a Pretare value is set, zero is not displayed and [- Pretare value] is displayed.
＊3 Units other than “g” must be set up before they can be used for measurement. Only gram
(g), percent (%), and piece counting (PCS) are set-up before shipment. To set up other
units or specific gravity measurement, refer to section 12., or 14.1, 14.2.
＊4 When the unit is set to 10d, the resolution of the minimum display is decreased by one
decimal place.
＊5 In Pouring mode (See 11.2), the right-most part of [O/T] key marked with a circle
functions as the switch for environmental condition setting. Otherwise this part functions
the same way as the other parts of [O/T] key.
During Weighing
Key
Press Once and Release Press and Hold for About 3 Seconds
[POWER] Returns to the previous menu level Returns to the mass display.
[CAL] Moves to the next menu item.
Displays the last menu item that was set.
(Last Menu Recall)
[O/T]
Selects or sets the currently displayed menu item,
or enter into the displayed menu.
No operation.
[UNIT] Increases the numeric value of the blinking digit by 1. No operation.
[PRINT] Moves to the next digit during numeric value entry. No operation.
