65
Upper threshold < Sample weight HI
Lower threshold ≤ Sample weight ≤ Upper threshold GO
Sample weight < Lower threshold LO
The decimal point is invisible in each value setting display. Setting the value cannot be
made in gram unit. Determine the number based on the minimum display of the
balance. For example, if the balance’s minimum display is 0.01g, 150g (150.00g in this
balance) must be set by inputting“15000” in the display, not “150” or “150.00”.
13.1.3 Target Mode
This mode is useful for constant amount weighing of liquid or judgment of excess and
shortage. The target value is the numeric value that is the desired amount in the unit that is
used for weighing. The limit value is the numeric amount above or below the target value that
is acceptable. The target will be indicated as the center line in the analog display. The limits
will be indicated as triangle marks. A moving bar represents the current weight on the pan.
Displays in use
1. Select the Target mode with menu item 12 .
2. Set the “target” value, which corresponds to the
center line of the graphic display, with menu item
13 .
Without load With a load within
the limit range
3. Set the “limit” value, which corresponds to the
distance between the center line and upper or lower
triangle marks, with menu item . 14 .
The decimal point is invisible in each value setting display. Setting the value cannot be
made in gram unit. Determine the number based on the minimum display of the
balance. For example, if the balance’s minimum display is 0.01g, 150g (150.00g in this
balance) must be set by inputting“15000” in the display, not “150” or “150.00”.
