91
15.2.3 Using Command Codes
If communication conditions are incorrectly set, a communication error message
“ComErr” is displayed.
(1) Commands that end with a number, character, or symbol other than [=]: Transmit to the
balance with a delimiter for each command code.
Example 1: PRINT<CR> ... The same operation as pressing the [PRINT] key
(2) Commands that end with a [=]: Transmit the number to the balance with a delimiter.
Example 2: TIME=1234 <CR> .. 12:34 is set as the current time.
Example 3: P.TARE=1.23 <CR> (example of type of the second decimal place).
...1.23g is set as a Pretare value.
Example 4: P.TARE=0.00 <CR> (example of the second decimal place)
...Clears (cancels) the Pretare value.
Number of digits, decimal point, position of decimal point of the numeral transmitted
succeeding to ‘=’ are the same as the case of setting the numeric value using the AKB-
301 Application Keyboard.
Use the same number of decimal places as in the gram-display.
This restriction does not apply to USER=, SOLID=, and LIQUID=.
Example 5: MENU=4630 <CR> (4-digit number after [=])
This is the same in the following operation.
.. from mass display, press the [CAL] key five times, then press the [O/T] key
once and the press the [CAL] key six times. This returns to the same display
as if the [CAL] key was never pressed.
Press the [O/T] key once, then [CAL] key three times, and the [O/T] key
once more.
This example indicates that menu item 25 (Anti-vibration mode) is selected.
