90
(ii) Verified balance as a legal measuring instrument
The brackets “[ ]” bordering auxiliary indicating device of legal measuring instrument can
also be outputted. In this case, “[” and “]” are inserted according to their positions in the
weighed data. They come to the positions before and after Position No.9 in the example.
Consequently, the data becomes 2 bytes longer.
(iii) Unit expressed with three letters
Some weighing units are expressed with three letters. Therefore one more byte is inserted
after Position No.11 in the above example. Consequently, the data becomes 1 byte longer.
(iv) When the delimiter “C/R+L/F” is selected (Menu item No. 96 . Refer to 15.3.7.)
The delimiter information requires one more character. Therefore one more byte is added
after Position No.12 in the above example. Consequently, the data becomes 1 byte longer.
(3) Data format in case of “oL” or “-oL” (Overload)
The below is the data format for “oL”.
Data Lenght of this example : 12bytes
Position 1 2 3 4 5 6 7 8 9 10 11 12
ASCⅡ
Code
2DH 2OH 2OH 2OH 2OH 36H 4FH 4CH 2OH 2OH 2OH ODH
Data - O L C/R
For “-oL” (negative overload), Position 1 is replaced with “-” (minus, ASCII code: 2DH).
The following parts appearing in “(2) Information of additional bytes” also apply to (3).
(i) Output with stability information
(iv) When the delimiter “C/R+L/F” is selected
