15.2 Personal Computer - RS-232C -
15.2.1 Connecting the Cable
Correctly connect an appropriate cable for communication between the balance and
personal computer. Some types of personal computers may not operate normally when
connected with the optional RS-232C cable according to the diagram.
(1) IBM PC/AT and compatible personal computer (D-sub 9-pin)
(2) IEEE Standard (D-sub 25-pin)
To Next Page
