6-WORKINGOPERATIONS

Liftingthemachine

NOTICE:Beforeliftingthemachine,itisessentialtoplace

thebackhoeattachmentintheroadtravelposition.

Thehookingpointsforthemachineareshownbydecals.

NOTICE:Neveruseanyotherhookingpointsthanthose

shownbythedecals.

Usesuitableslingstoliftthemachine.Makesurethatthe

slingsareinperfectconditionandthattheycansupport

theweightofthemachine.

NOTE:Donotallowanybodywithinthemachine’swork-

ingrange.Neversuspendthemachineoverpeoplewho

areinproximity.

PTIL14TLB0028AB1

6-5
