Case 570T User Manual

6-WORKINGOPERATIONS
Operatingtheloaderattachment
WARNING
Unexpectedmovement!
Implementsequippedwithrear-mountedattachmentsorrear-towedequipmentmaytipbackwhendis-
connectingfromthetractorinthetransportposition.Usearearjackstandtopreventtheimplement
fromtippingback.
Failuretocomplycouldresultindeathorseriousinjury.
W0917A
Thefollowinginstructionsdonotcoverallpossiblecondi-
tionsofuseoftheloaderattachment.Theyonlyconstitute
basicinformationtoenablethemachinetobeoperated
correctly.Wherepossible,alwaysusetheloaderattach-
mentatfullenginespeed.Thersttimeitisoperated,
maneuverthemachineinacleararea,atlowspeed.
NOTE:Alwaysplacethebackhoeintransportpositionfor
betterstabilityandtractionwhenevertheloaderisused.
Loadingoperations
Tollthebucketfromastockpile,setthebucketinthe
levelpositionandlowertheattachmentwiththecontrol
leverto“oat”position.
PTIL14TLB0029AA1
Whentheloaderhasenteredthepile,pressdownthe
transmissiondisconnectbutton,allowthecontrollever
tomovebackwardsandthensimultaneouslyoperatethe
controlstoliftandrollbackthebucket.
Liftandroll-backofthebucketwillincreaseefciencyasa
levelbucketthroughouttheliftingcycleresistsbucketlift
andincreasesbreakawayeffort.
NOTE:Donotbeconcernedifthebucketisnotcom-
pletelylledduringeachpass.Maximumproductivityis
determinedbytheamountofmaterialloadedinagiven
periodoftime.Timeislostiftwoormoreattemptsare
madetollthebucketoneachpass.
PTIL14TLB0030AA2
6-8
