3
-
CONTROLS
AND
INSTRUMENTS
Right-hand
stabilizer
right-hand
control
lever
The
lever
(1)
has
two
positions:
Position
“A”:
The
right-hand
stabilizer
lowers.
Position
“B”:
The
right-hand
stabilizer
rises.
NOTE:
T
o
raise
or
lower
the
two
stabilizers
at
the
same
time,
operate
the
two
levers
simultaneously
.
NOTICE:
Before
machine
travel
or
before
using
the
loader
attachment,
make
sure
the
stabilizers
are
com-
pletely
raised.
During
road
travel,
the
stabilizers
must
be
completely
raised.
PTIL12TLB0492AB
