Case 570T User Manual

7-MAINTENANCE
EVERY250HOURS
Stabilizerwearpadsadjust
Yourmachineisttedwithstabilizersleevelockingwith
plasticpadarrangementtoprovidecomforttotheoperator
duringbackhoeoperationbyreducingtheplaybetween
sleeve&verticalouter.
Whenmachineisinoperationthereisadenedclearance
betweenverticalouter&innersleeve.
Thisgapincreasesasthemachinecontinuestooperate.
Thisdanglingofthemachinecanbecontrolledbyplastic
padsprovidedinsidetheH-framewhichpushesagainstthe
innersleevetomaintainminimumclearancebetweenthe
verticalouterresultingminimumplay.
Astheinnersleevecomesoutoftheverticalouterduring
backhoeoperationeverytimeitwearsoutplasticpadre-
sultinginbuildingofclearance&subsequentdanglingof
themachine.Thepadsmustbereplacediffoundwornout
ordamaged.
1.Unscrewthe4numbersM10bolts(1)alongwithcon-
icalwashers(2)&takeoutcoversleevelocking(3)
alongwithshims(4).
PTIL12TLB0483AB1
2.Insertcoversleevelocking(3)alongX-directiononly
behindthepad(5)fromoutside&pressrmlywith
hand.
PTIL12TLB0486AB2
7-37
