Case 570T User Manual

7-MAINTENANCE
3.Insert&countthenumberofshims(4)instepcre-
atedbetweensleevelocking(3)&weldedboss(6)in
pressedconditionasshowningure.
4.Addonemoreshim(4)tothenumberofshims(4)count
inStep3tofrontofcoversleevelocking(3).
5.Placetheremainingshims(4)onbackofcoversleeve
locking(3).
PTIL12TLB0485AB3
6.Assemblethewholearrangementinsidethehole&
tightitthrough4numbersM10bolts(1)&conicalwash-
ers(2).
PTIL12TLB0484AB4
PTIL12TLB0487AA5
7.Followthesameprocedurefortheotherlocationalso.
Followthesameprocedurewheneverdothesettingfor
stabilizers.
7-38
