7
-
MAINTENANCE
Rear
axle
differential
oil
-
Replace
1.
Follow
Machine
safety
position.
(Refer
Engine
-
Safety
rules
)
2.
Place
a
container
with
suitable
capacity
under
the
plug
(1)
.
3.
Unscrew
and
remove
the
plugs
(1)
and
(2)
.
4.
Let
the
oil
drain
completely
(1)
.
5.
Screw
in
the
plug
(1)
.
T
orque:
60
N·m
(
44
lb
ft
).
6.
Fill
with
clean
oil
through
the
hole
of
the
plug
(2)
until
the
level
reaches
the
hole.
7.
Retighten
the
plug
(2)
.
NOTE:
Differential
oil
capacity
.
Refer
to
uid
and
lubricants
supply
summary
table.
PTIL12TLB0254AB
1
7-50
171
173
