5-TRANSPORTOPERATIONS
PREPARINGFORROADTRANSPORT
Preparingthemachineforroadtravel
1.Makesurethattheengineacceleratorlever(2)isin
lowidleposition.
PTIL12TLB0430AB1
2.Placetheseatinthebackhoeattachmentposition.
3.Placethebackhoeattachmentinroadtravelposition.
PTIL14TLB0021AA2
4.Stoptheengineandremovethestarterkey.Turnthe
seatbacktoloaderattachmentposition.
5.Applythewarningplate(3)tothebucketcylinderrod
orchassis.
PTIL14TLB0022AB3
6.Correctlyadjusttherearviewmirrors(5).
PTIL14TLB0023AB4
5-3
