7-MAINTENANCE
Hydraulicoillter-Replace
1.FollowMachinesafetyposition.(ReferEngine-Safety
rules)
2.Cleantopportionofthetank.
3.Removebreather(1)withaspecialtooltoreleasepres-
sureinsidetank.
PTIL12TLB0457AB1
4.Dismantleboltsandnuts(2)ofthetopcover(3)oflter
assemblyandremovethetopcover.
NOTE:Ensurethatsensor&O-ringdonotgetdamaged.
5.Cleanmagnetsoninnersurfaceofthistopcover.
6.Removethespringfromlterassembly.
7.Removethelterandseparatethecapfromit.
8.T akeanewlterandtthecaponit.
9.Putthelterinsidethelterassembly.
10.Installspringonit.
11.InstalltopcoverwiththeO-ringandboltsandnuts.
12.Installbreather(1)withaspecialtool.
PTIL12TLB0551AB2
