7-MAINTENANCE

Fueltanklevel-Check–Level

WARNING

Firehazard!

Whenhandlingdieselfuel,observethefollow-

ingprecautions:

1.Donotsmoke.

2.Neverllthetankwhentheengineisrun-

ning.

3.Wipeupspilledfuelimmediately.

Failuretocomplycouldresultindeathorseri-

ousinjury.

W0099A

1.FollowMachinesafetyposition.(ReferEngine-Safety

rules)

2.Nowitispossibletocheckthequantityoffuelinthe

tankbylookingattherelevantgauge(1)intheside

instrumentpanel.

NOTE:Itisrecommendedtollfreshfuelattheendofthe

dayorshift.

PTIL14TLB0008AB1

7-21
