7-MAINTENANCE

Greasepoints–Lubricate

Driveshaft’scoupling

Greasettings(1).

PTIL12TLB0219AB1

Frontaxleswivelbearing

Greasettings(1).

NOTE:Thenumberofgreasepointsmayvarydepending

onthetypeofaccessoryinstalled.

PTIL12TLB0212AB2

7-23
