6-WORKINGOPERATIONS

Tonishtherearwallcrowdinthebucket,whileliftingwith

theboom,keepingtheedgesofthebuckethorizontal.

Theplatformwillalsoreducethepossibilityofthemachine

creepingrearwardsifharddiggingisencountered.

NOTICE:Donotbackllatrenchusingtheswingdevice

toswingthebucketsideways.Doingsocandamagethe

dipstick,boom,swingcylindersormainframe.

PTIL12TLB0161AB4

Tobackllatrench,liftthebucketoverthespoilpileand

thencrowdinthedipperandlifttheboom.Pullboththe

crowdandboomleverssimultaneouslyforsmootheven

backlling.

PTIL12TLB0162AB5

6-20
