1-GENERALINFORMATION

Engineidenticationplate

Theengineidenticationplateisonthetappetcover.

PTIL12TLB0006BA2

Transmissionidenticationplate

Thetransmissionidenticationplateisontherighthand

sideoftheoilsump.

PTIL12TLB0007AA3

1-7
