9-SPECIFICATIONS

Loaderperformancewithbottomdumpbucket(iftted)

PTIL14TLB0048FA6

S.No.

Description

Dimension

Maximumheight

4140mm(162.99in)

Maximumheightofloaderbucketpin/pivot3478mm(136.93in)

Maximumdumpingheight

2732mm(107.56in)

Diggingdepth

106mm(4.17in)

Loaderattachmentreachwhenraisedindumpingposition

751mm(29.57in)

Angleofloweredclosedbucket

37°

Angleofclosedbucketatmaximumheight

62°

Dumpingangle

45°

9-9
