Case 570T - Loader bucket assy 6 in 1

246 pages

Save Page as PDF

To Next Page

To Previous Page

10-ACCESSORIES

Loaderbucketassy6in1

PTIL12TLB0477FB2

S.No

Description

1Rearbucket-Blade

Centretooth-Bucket

3Bolt

Nylocknut

Hexscrew

Pin-forkliftlocking(BDB)

Washer

8Washer

Dodgingblade

Squareholewasher

Bucketclamp

10-2
