10-ACCESSORIES

Backhoebuckets

Backhoebucketassy(0.26m³(9.2ft³))

PTIL12TLB0460FB1

S.No

Description

1Backhoebucket

Centretooth-bucket

Sidecuttingtoothleft-handside

Sidecuttingtoothright-handside

Bolt

6Bolt

Washer

Nylocknut

10-5
