3-CONTROLSANDINSTRUMENTS
Windows
Rearwindows
Turnthehandle(1)oneithersidetounlockthewindow(2).
Pushthewindowoutwardsandupwardssimultaneously
toopenituntilitengageswiththelockingdevice.
PTIL12TLB0189AB3
Sidewindows
Unlockthetopandbottomlocks(1)andswingthewin-
dowoutwards.Thewindowscanbepartiallyopenedand
lockedtothedoorwiththehelpoftheslot(A)inthelock.
Thewindowscanalsobecompletelyopenedandlocked
tothesiderearwindowswiththehelpofalockingmech-
anism(2).
NOTICE:Makesurethewindowiscompletelylocked.
PTIL14TLB0055AB4
Pressthelock(1)toreleasethewindowfromthelocking
mechanism.Swingthewindowinwardsandlockthewin-
dowtothedoor.
NOTICE:Makesurethewindowiscompletelylocked.
PTIL14TLB0054AB5
3-2
