Analogue Output Setup [532]
Preset scaling and offset of the output configuration.
Analogue Output Advanced [533]
With the functions in the “AnOut Advanced” menu, the
output can be completely defined according to the
application needs. The menus will automatically be adapted
to “mA” or “V”, according to the selection in “AnOut Setup”
[532].
Analogue Output Minimum [5331]
This parameter is automatically displayed if “User mA” or
“User V” is selected in menu “AnOut Setup” [532]. The
menu will automatically adapt to current or voltage setting
according to the selected setup. Only visible if [532] = “User
mA/V”.
Analogue Output Maximum [5332]
This parameter is automatically displayed if “User mA” or
“User V” is selected in menu “AnOut Setup” [532]. The
menu will automatically adapt to current or voltage setting
according to the selected setup. Only visible if [532] = “User
mA/V”.
AnOut Function Minimum [5334]
With “AnOut Function Min” the physical minimum value is
scaled to selected presentation. The default scaling is
dependent of the selected function of AnOut [531].
Table 30 shows corresponding values for the min and max
selections depending on the function of the analogue output
[531].
Default: 4-20mA
4–20mA 0
The current output has a fixed threshold
(Live Zero) of 4 mA and controls the full
range for the output signal.
0–20mA 1
Normal full current scale configuration of
the output that controls the full range for
the output signal.
User mA 2
The scale of the current controlled output
that controls the full range for the output
signal. Can be defined by the advanced
AnOut Min and AnOut Max menus.
0 - 10V 4
Normal full voltage scale configuration of
the output that controls the full range for
the output signal.
2–10V 5
The voltage output has a fixed threshold
(Live Zero) of 2 V and controls the full
range for the output signal.
User V 6
The scale of the voltage controlled output
that controls the full range for the output
signal. Can be defined by the advanced
AnOut Min and AnOut Max menus.
NOTE: When “AnIn” is selected in menu [531], the setup
of the “AnOut” [532] has to be set to 0-10 V or 0-20 mA.
When the “AnOut Setup” is set to e.g. 4-20 mA, the
mirroring is not working correctly.
532 AnOut Setup
Stp 4-20mA
Default: 4.00 mA
Range: 0.00 – 20.00 mA, 0 – 10.00 V
Default: 20.00 mA
Range: 0.00–20.00 mA, 0–10.00 V
Default: Min
Min 0 Min value
Max 1 Max value
User Defined 2 Define user value in menu [5335]
Ta b l e 3 0
AnOut
Function
Min Value Max Value
Process Value Process Min [324] Process Max [325]
Shaft Power 0 W Motor Power [223]
Current 0 A Motor Current [224]
5332 AnOut Max
Stp 20.00mA
