114 Functionality CG Drives & Automation, 01-5980-01r2
Relay 2 [552]
This menu sets the function for the relay output 2.
Relay 3 [553]
This menu sets the function for the relay output 3.
Board Relay [554] to [559]
These additional relays are only visible if an I/O option board
is fitted in slot 1 or 2. The outputs are named “B1 Relay 1” -
“B1 Relay 3” and “B2 Relay 1” - “B2 Relay 3”. “B” stands for
“board” and 1 and 2 is the number of the board which is
related to the position of the I/O option board on the option
mounting plate. The functions and selections are the same as
for “Relay 1” [551]. Default settings are “Off ”.
Relay Advanced [55D].
Relay 1 Mode [55D1]
Relay Modes [55D2] to [55DC]
Same function as for “Relay 1 Mode” [55D1]. Default
settings are “N.O”.
NOTE: The definitions described here are valid for the
active output condition.
Default: Off
Selection:
Same selection as in menu Relay 1 [551],
page 112.
Default: Trip
Selection:
Same selection as in menu Relay 1 [551],
page 112.
NOTE: Visible only if optional board is detected or if any
input/output is activated.
Default: N.O
N.O 0
The normal open contact of the relay will
be activated when the function is active.
N.C 1
The normally closed contact of the relay
will act as a normal open contact. The
contact will be opened when function is
not active and closed when function is
active.
