Reset priority
“Reset priority” means that if both input signals are active, it
will be the RESET command that is obeyed, causing the
output signal to become inactive (=0). See Table 33.
Set priority
For “Set priority” the determining input signal is SET.
Should both input signals be active, this is resulting in an
activated (=1) output signal. See Table 34.
Edge controlled without priority
The third setting is “Edge controlled”, for which no input
signal has priority over the other. The output signal follows
any of the two input signals (still providing they are at a
positive edge). The most recent registered activity decides the
output. See Table 35.
Should both inputs become activated simultaneously, there
will not be any change; the output signal will just keep its
earlier status.
Flip-flop 1 [641]
Functions for SR flip-flop 1.
Flip-flop 1 Mode [6411]
Priority setting of input signals for flip-flop 1.
Flip-flop 1 Set [6412]
Selection of SET input signal for flip-flop 1.
Flip-flop 1 Reset [6413]
Selection of RESET input signal for flip-flop 1.
Flip-flop 1 Set Delay [6414]
The SET input signal for flip-flop 1 is delayed with the set
value in this menu.
Table 33 Truth table for Reset priority
SET RESET OUT
00- (no change)
0 1 0 (reset)
101 (set)
1 1 0 (reset)
Table 34 Truth table for Set priority
SET RESET OUT
00- (no change)
0 1 0 (reset)
101 (set)
111 (set)
NOTE: The input signals are updated in intervals of 8
milliseconds, therefore the signal changes are
considered simultaneous if the difference is less than 8
ms.
Table 35 Truth table for Edge control without priority
SET RESET OUT
00- (no change)
1 0/1 1 (set)
0/1
1 0 (reset)
1 1 No change
Default: Reset
Reset 0 Reset priority.
Set 1 Set priority.
Edge 2 Edge controlled without priority.
Default: Off
Selection:
Same selections as in menu Relay 1 [551], page
112.
Default: Off
Selection:
Same selections as in menu Relay 1 [551], page
112.
Default: 0:00:00.0 (hours:minutes:seconds)
Range: 0:00:00.0–9:59:59.9
6411 F1 Mode
Stp Reset
6412 F1 Set
Stp Off
6413 F1 Reset
Stp Off
6414 F1 Set Dly
Stp 0:00:00.0
