CHCNAV CHC i83 - Manually Converting Heights; Examples

CHC i83 User Manual 70
Manually Converting Heights
Receiver
Radius
r (meters)
SHMP
h (meters)
i83
0.1240 0.0
 

s

 r

v:
vertical height
s:
slant height
r: Length of Measure-Up-Bar
The SHMP is 0.000 m.
Examples
Measured
Slant s
(feet)
Slant s
(m)
Vertical
v (m)
6.965 2.123 2.119
5.148 1.569 1.564
