System testing 7-35
6200 Packet-Optical Platform Installation, Commissioning, and Testing Procedures
Release 1.1 009-6200-201 Draft Issue 1
Copyright
©
2014 Ciena
®
Corporation September 2014
Procedure 7-7 (continued)
Testing STM-1/4/16/64/OC-3/12/48/192 protection switching with traffic on 4xFE interfaces of
4xGE + 4xFE circuit pack
Step Action
Table 7-8
For SNCP/UPSR mode
4 Daisy-chain the Ethernet ports of the near end network element as shown in
Table 7-9.
Table 7-9
Daisy-chain the Ethernet ports
5 Generate traffic with the Ethernet test set (15 Mbit/s, full duplex) and verify
that no packets are lost.
6 Record the data in the Table 12-6 on page 12-7. The result verifies that all the
Ethernet ports and optical ports function correctly.
WAN STM/OC port
number must be
KLM value STS #, VT-Group, VT #
value
SDH SONET
1 1, 2 1-1-1 to 1-3-1 1-1-1 to 1-3-2
2 1, 2 1-3-2 to 1-5-2 1-3-3 to 1-5-4
3 1, 2 1-5-3 to 1-7-3 1-6-1 to 2-1-2
4 1, 2 2-1-1 to 2-3-1 2-1-3 to 2-3-4
5 1, 2 2-3-2 to 2-5-2 2-4-1 to 2-6-2
6 1, 2 2-5-3 to 2-7-3 2-6-3 to 3-1-4
7 1, 2 3-1-1 to 3-3-1 3-2-1 to 3-4-2
8 1, 2 3-3-2 to 3-5-2 3-4-3 to 3-6-4
From port To Cable used for connectivity
one Ethernet test set straight
two three cross
four Ethernet test set straight
