Cleaning connectors 9-7
6200 Packet-Optical Platform Installation, Commissioning, and Testing Procedures
Release 1.1 009-6200-201 Draft Issue 1
Copyright
©
2014 Ciena
®
Corporation September 2014
Procedure 9-2 (continued)
Cleaning optical connectors and adapters on patch cords
Step Action
Connecting the optical connector
13 Determine your next step.
14 Place the connector in a clean adapter housing to prevent the ferrule from
coming in contact with any dirt.
Note: Never place a clean connector in an adapter that has not been
cleaned.
15 Inspect and clean the optical interface internal connectors and fiber. See
Procedure 9-1, Inspecting and cleaning optical interface internal connectors
and fiber.
Connecting the optical connector to the circuit pack
16 Insert the ferrule into the sleeve so the guide pin enters the guide slit. See
Figure 9-1 on page 9-8.
17 Hold the adaptor retainer and lock it in by pushing it into the connector.
18 Repeat step 16 and step 17 for the second connector and adapter.
You have completed this procedure.
—end—
If you want to Then go to
inspect and clean the optical
interface internal connectors and
fiber
step 14
connect the optical connector to the
circuit pack
step 16
