Common procedures 10-5
6200 Packet-Optical Platform Installation, Commissioning, and Testing Procedures
Release 1.1 009-6200-201 Draft Issue 1
Copyright
©
2014 Ciena
®
Corporation September 2014
Procedure 10-2 (continued)
Ejecting the power supply unit-DC PSU/Fan+OAM/Fan+OAMV2 module
Step Action
3 Remove the screw located on the face plate using a manual Phillips (PH1)
screwdriver.
4 Disengage the module from the backplane connector.
5 Eject the power supply unit-DC PSU/Fan+OAM/Fan+OAMV2 module.
Note: Fan module is hot swappable. Hot swappable is the ability to replace
a defective component while the system continues to function normally.
6 Pull out the module using the puller along the guide way.
—end—
CAUTION
Risk of Service disruption
The power supply unit is not hot swappable.This action
is service disruption.
where is in
power supply unit-DC PSU slot 8/ slot 9
Fan+OAM or Fan+OAMV2 slot 10
