5-16 Installing the 6200 network element
6200 Packet-Optical Platform Installation, Commissioning, and Testing Procedures
Release 1.1 009-6200-201 Draft Issue 1
Copyright
©
2014 Ciena
®
Corporation September 2014
Procedure 5-4 (continued)
Connecting the AC power supply
Action
Step Action
1 Make sure that the circuit breaker feeding power to 6200 network element is
switched off.
2 Connect the power cable to the power supply connector as shown in Figure
5-7 on page 5-17. The figure also displays an APU filler panel that covers the
gap between the AC power supply unit and the optical card above, refer Note
2.
Note: On pulling out one of the two base power cables, the network element
raises the circuit pack missing alarm for the PSU circuit pack corresponding
to this power cable.
3 Route the power cable securely along the left side of the rack as shown in
Figure 5-7 on page 5-17 and then connect them to the power distribution
panel.
4 For connecting the power cable to second AC power feed on base chassis,
repeat steps 1 to 3.
5 Power on the circuit breaker feeding power to the 6200 network element.
6 Verify that the Power LED is turned on with green color for the two PSU circuit
packs.
—end—
CAUTION
Risk of equipment damage
Electrostatic discharge can damage electrostatic sensitive
devices. Use antistatic protection to avoid damaging the shelf
and circuit packs.
