OPERATOR’S MANUAL PRO SERIES
7 MAINTENANCE
7.7 TIPPER LUBRICATION
The embossed cards Inking device (Tipper) needs,
apart from the Ribbon change, to be oiled periodically.
This is done by oiling the 2 service holes (1) e (2)
1
located on the upper face and on the 2 sides.
Repeat this operation every 20 days or every 1500
produced cards.
Every 6 months the internal mechanical parts should
receive a general greasing. This can be done however
only by a specialised person.
When the general maintenance is finished switch the
embosser on and control that the front cover blocks all
2
operations. If this not the case call the Technical
Assistance because one or more safety devices could
be damaged.
Check the ribbon tensioning rack (3) is greased and the
shafts (4) which allow the ribbon movement are
lubricated.
3
3
4
