OPERATOR’S MANUAL PRO SERIES
A MACHINE SET UP
Example: How to modify the Baud Rate from 4800 to
9600
CHOICE OF THE BAUD RATE
(11,15,3,6,12,24,48,96) (4800) 9600
WHERE:
CHOICE OF THE BAUD RATE = name of the
parameter
(11,15,3,6,12,24,48,96) = possible values
(4800) = current value
To modify the value of the parameter displayed, press,
on the keypad, the number corresponding to the
position to the left of the value required (the
corresponding selection is displayed on the left of the
display unit beside the current value) and then press
Enter.
Example: how to modify the Baud rate in the
Protocols menu
•
To set a Baud Rate of 9600, do the following:
•
Press key “8” corresponding to the eighth possible
value (96), namely 9600. The left of the display unit
will display the corresponding selection:
•
Then press to save the new value.
•
Press "ABORT" twice to quit set-up and apply the
modifications.
For parameters for which you can enter number values,
only the actual possible values are indicated. In this
case, on the keypad, type the new value, making sure
you specify the sign, if required.
Specify the sign, if required, by typing:
"1" for "+"
and "2" for "-".
Example: how to modify a mechanical parameter
To modify value +04 proceed as follows:
X TOTAL ADJ
(-99/+99) (+/- = 1/2) (00)
•
Press keys "1; 0; 4" in sequence. The new value
will be displayed.
X TOTAL ADJ
(-99/+99) (+/- = 1/2) (00)+04
ENTER
•
Press to confirm.
