Port Management
Setting Port Configuration
128 Cisco Small Business 200, 300 and 500 Series Managed Switch Administration Guide (Internal Version)
9
- MDI—Select to connect this device to a station by using a straight
through cable.
- Auto—Select to configure this device to automatically detect the correct
pinouts for the connection to another device.
• Operational MDI/MDIX—Displays the current MDI/MDIX setting.
• Protected Port—Select to make this a protected port. (A protected port is
also referred as a Private VLAN Edge (PVE).) The features of a protected port
are as follows:
- Protected Ports provide Layer 2 isolation between interfaces (Ethernet
ports and LAGs) that share the same VLAN.
- Packets received from protected ports can be forwarded only to
unprotected egress ports. Protected port filtering rules are also applied
to packets that are forwarded by software, such as snooping
applications.
- Port protection is not subject to VLAN membership. Devices connected
to protected ports are not allowed to communicate with each other, even
if they are members of the same VLAN.
- Both ports and LAGs can be defined as protected or unprotected.
Protected LAGs are described in the Configuring LAG Settings section.
• Member in LAG—If the port is a member of a LAG, the LAG number
appears; otherwise this field is left blank.
STEP 6 Click Apply. The Port Settings are written to the Running Configuration file.
Error Recovery Settings
This page enables automatically reactivating a port that has been shutdown
because of an error condition.
To configure error recovery settings:
STEP 1 Click Port Management > Error Recovery Settings.
STEP 2 Enter the following fields:
• Automatic Recovery Interval—Select to enable the error recovery
mechanism for the port security err-disable state.
