Cisco 300 Series Administration Guide

Security: 802.1X Authentication
Defining Time Ranges
Cisco Small Business 200, 300 and 500 Series Managed Switch Administration Guide (Internal Version) 407
19
STEP 15 Enter the Success Message, which is the text that will be displayed if the end user
successfully logs in.
STEP 16 Click Apply and the settings are saved to the Running Configuration file.
To preview the login or success message, click Preview.
To set one of the languages as the default language, click Set Default Display
Language.
Defining Time Ranges
See <300-500>Time Range for an explanation of this feature.
Authentication Method and Port Mode Support
The following table shows which combinations of authentication method and port
mode are supported.
Legend:
†—The port mode also supports the guest VLAN and RADIUS-VLAN assignment.
N/S—The authentication method does not support the port mode.
NOTE Web-based authentication requires TCAM support for input traffic classification
and can be supported only by the full multi-sessions mode. You can simulate the
single-host mode by setting Max Hosts parameter to 1 in the Port Authentication
page.
Authentication
Method
Single-host Multi-host Multi-sessions
Device in L3 Device in L2
802.1x
††††
MAC
††††
WEB
N/S N/S N/S †

Cisco 300 Series Specifications

General

Model	Cisco 300 Series
Category	Switch
Dimensions	Varies by model
Weight	Varies by model
Power over Ethernet (PoE)	Available on select models
Management	Web-based GUI, SNMP, CLI
VLANs	Up to 256
Security Features	ACLs, 802.1X, Port Security
Humidity	10% to 90% non-condensing
Ports	8, 16, 24, 48
