Cisco 300 Series Administration Guide

VLAN Management
Customer Port Multicast TV VLAN
Cisco Small Business 200, 300 and 500 Series Managed Switch Administration Guide (Internal Version) 229
13
After a CPE VLAN is mapped to a Multicast VLAN, it can participate in IGMP
snooping.
To m a p C P E V L A N s :
STEP 1 Click VLAN Management > Customer Port Multicast TV VLAN > CPE VLAN to
VLAN.
STEP 2 Click Add.
STEP 3 Enter the following fields:
• CPE VLAN—Enter the VLAN defined on the CPE box.
• Multicast TV VLAN—Select the Multicast TV VLAN which is mapped to the
CPE VLAN.
STEP 4 Click Apply. CPE VLAN Mapping is modified, and written to the Running
Configuration file.
CPE Port Multicast VLAN Membership
The ports associated with the Multicast VLANs must be configured as customer
ports (see Configuring VLAN Interface Settings).
Use the Port Multicast VLAN Membership page to map these ports to Multicast TV
VLANs as described in Port Multicast VLAN Membership

Cisco 300 Series Specifications

General

Model	Cisco 300 Series
Category	Switch
Dimensions	Varies by model
Weight	Varies by model
Power over Ethernet (PoE)	Available on select models
Management	Web-based GUI, SNMP, CLI
VLANs	Up to 256
Security Features	ACLs, 802.1X, Port Security
Humidity	10% to 90% non-condensing
Ports	8, 16, 24, 48
