Cisco 300 Series - Routing Resources

Administration
Routing Resources
Cisco Small Business 200, 300 and 500 Series Managed Switch Administration Guide (Internal Version) 67
5
Routing Resources
Use the Router Resources page to display TCAM allocation and modify total
TCAM size. TCAM entries are divided into the following groups:
• IP Entries—TCAM entries reserved for IP static routes, IP addresses on the
device, and IP hosts. Each type generates the following number of TCAM
entries:
- IPv4 static routes—One entry per route
- IP Addresses—Two entries per IP address
- IP Hosts—One entry per host
• Non-IP Entries—TCAM entries reserved for other applications, such as
ACL rules, CoS policers, and VLAN rate limits.
To view and modify router resources:
STEP 1 Click Administration > Router Resources.
The following fields are displayed:
• Neighbors—Count is the number of neighbors recorded on the device and
TCAM Entries is the total number of TCAM entries being used for neighbors.
• Interfaces—Count is the number of IP addresses on interfaces on the
device and TCAM Entries is the total number of TCAM entries being used for
the IP addresses.
• Routes—Count is the number of routes recorded on the device and TCAM
Entries is the total number of TCAM entries being used for the routes.
• Total—Displays the number of TCAM entries which are currently being
used.
• Maximum Entries—Select one of the following options:
- Use Default—The number of TCAM entries available for IP entries is
25% of the TCAM size.
- User Defined—Enter a value.
