Cisco 300 Series Administration Guide

Quality of Service
Managing QoS Statistics
Cisco Small Business 200, 300 and 500 Series Managed Switch Administration Guide (Internal Version) 516
25
Managing QoS Statistics
From these pages you can manage the Single Policer, Aggregated Policer, and
view queues statistics.
Policer Statistics
A Single Policer is bound to a class map from a single policy. An Aggregate Policer
is bound to one or more class maps from one or more policies.
Viewing Single Policer Statistics
The Single Policer Statistics page indicates the number of in-profile and out-of-
profile packets that are received from an interface that meet the conditions
defined in the class map of a policy.
NOTE This page is not displayed when the device is in Layer 3 mode.
To v i e w p o l i c e r s t a t i s t i c s :
STEP 1 Click Quality of Service > QoS Statistics > Single Policer Statistics.
This page displays the following fields:
• Interface—Statistics are displayed for this interface.
• Policy—Statistics are displayed for this policy.
• Class Map—Statistics are displayed for this class map.
• In-Profile Bytes—Number of in-profile bytes received.
• Out-of-Profile Bytes—Number of out-profile bytes received.
STEP 2 Click Add.
STEP 3 Enter the parameters.
• Interface—Select the interface for which statistics are accumulated.
• Policy Name—Select the policy name.
• Class Map Name—Select the class name.

Cisco 300 Series Specifications

General

Model	Cisco 300 Series
Category	Switch
Dimensions	Varies by model
Weight	Varies by model
Power over Ethernet (PoE)	Available on select models
Management	Web-based GUI, SNMP, CLI
VLANs	Up to 256
Security Features	ACLs, 802.1X, Port Security
Humidity	10% to 90% non-condensing
Ports	8, 16, 24, 48
