Cisco 300 Series Administration Guide

Administration: File Management
Active Image
42 Cisco Small Business 200, 300 and 500 Series Managed Switch Administration Guide (Internal Version)
4
• If SSH server authentication is not enabled, the operation succeeds for any
SCP server.
Active Image
There are two firmware images stored on the device. One of the images is
identified as the active image and other image is identified as the inactive image.
The device boots from the image you set as the active image. You can change the
image identified as the inactive image to the active image. (You can reboot the
device by using the process described in the Management Interface<print
only> section).
To select the active image:
STEP 1 Click Administration > File Management > Active Image.
The page displays the following:
• Active Image—Displays the image file that is currently active on the device.
• Active Image Version Number—Displays the firmware version of the active
image.
• Active Image After Reboot—Displays the image that is active after reboot.
• Active Image Version Number After Reboot—Displays the firmware
version of the active image as it be after reboot.
STEP 2 Select the image from the Active Image After Reboot menu to identify the
firmware image that is used as the active image after the device is rebooted. The
Active Image Version Number After Reboot displays the firmware version of the
active image that is used after the device is rebooted.
STEP 3 Click Apply. The active image selection is updated.

Cisco 300 Series Specifications

General

Model	Cisco 300 Series
Category	Switch
Dimensions	Varies by model
Weight	Varies by model
Power over Ethernet (PoE)	Available on select models
Management	Web-based GUI, SNMP, CLI
VLANs	Up to 256
Security Features	ACLs, 802.1X, Port Security
Humidity	10% to 90% non-condensing
Ports	8, 16, 24, 48
