Status and Statistics
Viewing GVRP Statistics
16 Cisco Small Business 200, 300 and 500 Series Managed Switch Administration Guide (Internal Version)
2
• Click View All Interfaces Statistics to see all ports on a single page.
Viewing GVRP Statistics
The GVRP page displays information regarding GARP VLAN Registration Protocol
(GVRP) frames that were sent or received from a port. GVRP is a standards-based
Layer 2 network protocol, for automatic configuration of VLAN information on
switches. It was defined in the 802.1ak amendment to 802.1Q-2005.
GVRP statistics for a port are only displayed if GVRP is enabled globally and on
the port. See the GVRP page.
To view GVRP statistics and/or set the refresh rate:
STEP 1 Click Status and Statistics > GVRP.
STEP 2 Enter the parameters.
• Interface—Select the specific interface for which GVRP statistics are to be
displayed.
• Refresh Rate—Select the time period that passes before the GVRP
statistics page is refreshed.
The Attribute Counter block displays the counters for various types of packets per
interface.
• Join Empty—Number of GVRP Join Empty packets received/transmitted.
• Empty—Number of GVRP empty packets received/transmitted.
• Leave Empty—Number of GVRP Leave Empty packets received/
transmitted.
• Join In—Number of GVRP Join In packets received/transmitted.
• Leave In—Number of GVRP Leave In packets received/transmitted.
• Leave All—Number of GVRP Leave All packets received/transmitted.
The GVRP Error Statistics section displays the GVRP error counters.
• Invalid Protocol ID—Invalid protocol ID errors.
• Invalid Attribute Type—Invalid attribute ID errors.
