Cisco 300 Series Administration Guide

IP Configuration
IPv4 Management and Interfaces
Cisco Small Business 200, 300 and 500 Series Managed Switch Administration Guide (Internal Version) 275
17
- Delayed—The assignment of the IP address is delayed for 60 second if
DHCP Client is enabled on startup in order to give time to discover DHCP
address.
- Not Received—Relevant for DHCP Address. When a DCHP Client starts
a discovery process, it assigns a dummy IP address 0.0.0.0 before the
real address is obtained. This dummy address has the status of “Not
Received”.
STEP 2 Click Add.
STEP 3 Select one of the following fields:
• Interface—Select Port, LAG, or VLAN as the interface associated with this
IP configuration, and select an interface from the list.
• IP Address Type—Select one of the following options:
-
Dynamic IP Address —Receive the IP address from a DHCP server.
-
Static IP Address —Enter the IP address.
STEP 4 SelectDynamic Address or Static Address.
STEP 5 If Static Address was selected, enter the IP Address for this interface, and enter
one of the following:
• Network Mask—IP mask for this address.
• Prefix Length—Length of the IPv4 prefix.
STEP 6 Click Apply. The IPv4 address settings are written to the Running Configuration
file.
IPv4 Routes
When the device is in Layer 3 system mode, this page enables configuring and
viewing IPv4 static routes on the device. When routing traffic, the next hop is
decided on according to the longest prefix match (LPM algorithm). A destination
IPv4 address may match multiple routes in the IPv4 Static Route Table. The device
uses the matched route with the highest subnet mask, that is, the longest prefix
match.

Cisco 300 Series Specifications

General

Model	Cisco 300 Series
Category	Switch
Dimensions	Varies by model
Weight	Varies by model
Power over Ethernet (PoE)	Available on select models
Management	Web-based GUI, SNMP, CLI
VLANs	Up to 256
Security Features	ACLs, 802.1X, Port Security
Humidity	10% to 90% non-condensing
Ports	8, 16, 24, 48
