Page #28 background imageLoading...
Page #28 background image
Status and Statistics
Viewing TCAM Utilization
18 Cisco Small Business 200, 300 and 500 Series Managed Switch Administration Guide (Internal Version)
2
• EAP Request/ID Frames Transmitted—EAP Req/ID frames transmitted by
the port.
• EAP Request Frames Transmitted—EAP Request frames transmitted by
the port.
• Invalid EAPOL Frames Received—Unrecognized EAPOL frames received
on this port.
• EAP Length Error Frames Received—EAPOL frames with an invalid Packet
Body Length received on this port.
• Last EAPOL Frame Version—Protocol version number attached to the most
recently received EAPOL frame.
• Last EAPOL Frame Source—Source MAC address attached to the most
recently received EAPOL frame.
To clear statistics counters:
• Click Clear Interface Counters to clear the selected interfaces counters.
• Click Clear All Interface Counters to clear the counters of all interfaces.
Viewing TCAM Utilization
The device architecture uses a Ternary Content Addressable Memory (TCAM) to
support packet actions in wire speed.
TCAM holds the rules produced by applications, such as ACLs (Access Control
Lists), Quality of Service (QoS), IP Routing and user-created rules.
Some applications allocate rules upon their initiation. Additionally, processes that
initialize during system boot use some of their rules during the startup process.
To view TCAM utilization, click Status and Statistics > TCAM Utilization.
The TCAM Utilization page shows the following fields:
• Maximum TCAM Entries for IPv4 and Non-IP (Rules)—Maximum TCAM
Entries available.
• IPv4 Routing
- In Use—Number of TCAM entries used for IPv4 routing.
