SNMP
Defining Trap Settings
535 Cisco Small Business 200, 300 and 500 Series Managed Switch Administration Guide (Internal Version)
26
Defining Trap Settings
The Trap Settings page enables configuring whether SNMP notifications are sent
from the device, and for which cases. The recipients of the SNMP notifications can
be configured in the Notification Recipients SNMPv1,2 page, or the Notification
Recipients SNMPv3 page.
To d e f i n e t r a p s e t t i n g s :
STEP 1 Click SNMP > Trap Settings.
STEP 2 Select Enable for SNMP Notifications to specify that the device can send SNMP
notifications.
STEP 3 Select Enable for Authentication Notifications to enable SNMP authentication
failure notification.
STEP 4 Click Apply. The SNMP Trap settings are written to the Running Configuration file.
Notification Recipients
Trap messages are generated to report system events, as defined in RFC 1215.
The system can generate traps defined in the MIB that it supports.
Trap receivers (aka Notification Recipients) are network nodes where the trap
messages are sent by the device. A list of notification recipients are defined as the
targets of trap messages.
A trap receiver entry contains the IP address of the node and the SNMP
credentials corresponding to the version that is included in the trap message.
When an event arises that requires a trap message to be sent, it is sent to every
node listed in the Notification Recipient Table.
The Notification Recipients SNMPv1,2 page and the Notification Recipients
SNMPv3 page enable configuring the destination to which SNMP notifications are
sent, and the types of SNMP notifications that are sent to each destination (traps
or informs). The Add/Edit pop-ups enable configuring the attributes of the
notifications.
An SNMP notification is a message sent from the device to the SNMP
management station indicating that a certain event has occurred, such as a link up/
down.
