Cisco 300 Series Administration Guide

Smartport
Configuring Smartport Using The Web-based Interface
Cisco Small Business 200, 300 and 500 Series Managed Switch Administration Guide (Internal Version) 171
11
- Enable by Auto Voice VLAN—This enables Auto Smartport, but puts it in
operation only when Auto Voice VLAN is also enabled and in operation.
Enable by Auto Voice VLAN is the default.
• Operational Auto Smartport—Displays the Auto Smartport status.
• Auto Smartport Device Detection Method—Select whether incoming
CDP, LLDP, or both types of packets are used to detect the Smartport type
of the attaching device(s). At least one must be checked in order for Auto
Smartport to identify devices.
• Operational CDP Status—Displays the operational status of CDP. Enable
CDP if Auto Smartport is to detect the Smartport type based on CDP
advertisement.
• Operational LLDP Status—Displays the operational status of LLDP. Enable
LLDP if Auto Smartport is to detect the Smartport type based on LLDP/
LLDP-MED advertisement.
• Auto Smartport Device Detection—Select each type of device for which
Auto Smartport can assign Smartport types to interfaces. If unchecked, Auto
Smartport does not assign that Smartport type to any interface.
STEP 3 Click Apply. This sets the global Smartport parameters on the device.
Smartport Type Settings
Use the Smartport Type Settings page to edit the Smartport Type settings and
view the Macro Source.
By default, each Smartport type is associated with a pair of built-in Smartport
macros. See Smartport Types for further information on macro versus anti-macro.
Alternatively, you can associate your own pair of user-defined macros with
customized configurations to a Smartport type. User-defined macros can be
prepared only through CLI. You should refer to the CLI reference guide for details.
Built-in or user-defined macros can have parameters. The built-in macros have up
to three parameters.
Editing these parameters for the Smartport types applied by Auto Smartport from
the Smartport Type Settings page configures the default values for these
parameters. These defaults are used by Auto Smartport.

Cisco 300 Series Specifications

General

Model	Cisco 300 Series
Category	Switch
Dimensions	Varies by model
Weight	Varies by model
Power over Ethernet (PoE)	Available on select models
Management	Web-based GUI, SNMP, CLI
VLANs	Up to 256
Security Features	ACLs, 802.1X, Port Security
Humidity	10% to 90% non-condensing
Ports	8, 16, 24, 48
