Cisco 300 Series Administration Guide

Security: 802.1X Authentication
802.1X Configuration Through the GUI
402 Cisco Small Business 200, 300 and 500 Series Managed Switch Administration Guide (Internal Version)
19
Viewing Authenticated Hosts
To view details about authenticated users:
STEP 1 Click Security > 802.1X/MAC/Web Authentication > Authenticated Hosts.
This page displays the following fields:
• User Name—Supplicant names that were authenticated on each port.
• Port—Number of the port.
• Session Time (DD:HH:MM:SS)—Amount of time that the supplicant was
logged on the port.
• Authentication Method—Method by which the last session was
authenticated.
• Authentication Server—RADIUS server.
• MAC Address—Displays the supplicant MAC address.
• VLAN ID—Port’s VLAN.
Locked Clients
To view clients who have been locked out because of failed login attempts and to
unlock a locked client:
STEP 1 Click Security > 802.1X/MAC/Web Authentication > Locked Client.
The following fields are displayed:
• Interface—Port that is locked.
• MAC Address—Displays the current port authorization state. If the state is
Authorized, the port is either authenticated or the Administrative Port
Control is Force Authorized. Conversely, if the state is Unauthorized, then
the port is either not authenticated or the Administrative Port Control is
Force Unauthorized.
• Remaining Time(Sec)—The time remaining for the port to be locked.
STEP 2 Select a port.
STEP 3 Click Unlock.

Cisco 300 Series Specifications

General

Model	Cisco 300 Series
Category	Switch
Dimensions	Varies by model
Weight	Varies by model
Power over Ethernet (PoE)	Available on select models
Management	Web-based GUI, SNMP, CLI
VLANs	Up to 256
Security Features	ACLs, 802.1X, Port Security
Humidity	10% to 90% non-condensing
Ports	8, 16, 24, 48
