Cisco 300 Series Administration Guide

Security: 802.1X Authentication
Authenticator Overview
Cisco Small Business 200, 300 and 500 Series Managed Switch Administration Guide (Internal Version) 389
19
After authentication is completed, the switch forwards all traffic arriving from the
client on the port, as shown in the figure below.
Figure 3 WEB-Based Authentication
Web-based authentication cannot be configured on a port that has the guest
VLAN or RADIUS-Assigned VLAN feature enabled.
Web-based authentication supports the following pages:
• Login page
• Login Success page
There is a predefined, embedded set of these pages.
These pages can be modified in the Security > 802.1X/MAC/Web Authentication
> Web Authentication Customization page.
You can preview each of the customized pages. The configuration is saved into
the Running Configuration file.
The following table describes which SKUs support web-based authentication and
in which system modes:
SKU System Mode WBA Supported
Sx300 Layer 2 Ye s
Layer 3 No
Sx500,
Sx500ESW2-
550X
Layer 2 Yes
Layer 3 No

Cisco 300 Series Specifications

General

Model	Cisco 300 Series
Category	Switch
Dimensions	Varies by model
Weight	Varies by model
Power over Ethernet (PoE)	Available on select models
Management	Web-based GUI, SNMP, CLI
VLANs	Up to 256
Security Features	ACLs, 802.1X, Port Security
Humidity	10% to 90% non-condensing
Ports	8, 16, 24, 48
