SNMP
Notification Recipients
539 Cisco Small Business 200, 300 and 500 Series Managed Switch Administration Guide (Internal Version)
26
• Recipient IP Address/Name—Enter the IP address or server name of
where the traps are sent.
• UDP Port—Enter the UDP port used to for notifications on the recipient
device.
• Notification Type—Select whether to send traps or informs. If both are
required, two recipients must be created.
• Timeout—Enter the amount of time (seconds) the device waits before re-
sending informs/traps. Timeout: Range 1-300, default 15
• Retries—Enter the number of times that the device resends an inform
request. Retries: Range 1-255, default 3
• User Name—Select from the drop-down list the user to whom SNMP
notifications are sent. In order to receive notifications, this user must be
defined on the SNMP User page, and its engine ID must be remote.
• Security Level—Select how much authentication is applied to the packet.
NOTE The Security Level here depends on which User Name was
selected. If this User Name was configured as No Authentication, the
Security Level is No Authentication only. However, if this User Name has
assigned Authentication and Privacy on the User page, the security level
on this screen can be either No Authentication, or Authentication Only, or
Authentication and Privacy.
The options are:
-
No Authentication
—Indicates the packet is neither authenticated nor
encrypted.
-
Authentication
—Indicates the packet is authenticated but not encrypted.
-
Privacy
—Indicates the packet is both authenticated and encrypted.
• Notification Filter—Select to enable filtering the type of SNMP notifications
sent to the management station. The filters are created in the Notification
Filter page.
• Filter Name—Select the SNMP filter that defines the information contained
in traps (defined in the Notification Filter page).
STEP 4 Click Apply. The SNMP Notification Recipient settings are written to the Running
Configuration file.
