Cisco CATALYST 2960 Command Reference Guide

2-229
Catalyst 2960 Switch Command Reference
OL-8604-03
Chapter 2 Catalyst 2960 Switch Cisco IOS Commands
mls qos srr-queue input cos-map
Usage Guidelines The CoS assigned at the ingress port selects an ingress or egress queue and threshold.
The drop-threshold percentage for threshold 3 is predefined. It is set to the queue-full state. You can
assign two weighted tail-drop (WTD) threshold percentages to an ingress queue by using the mls qos
srr-queue input threshold global configuration command.
You can map each CoS value to a different queue and threshold combination, allowing the frame to
follow different behavior.
Examples This example shows how to map CoS values 0 to 3 to ingress queue 1 and to threshold ID 1 with a drop
threshold of 50 percent. It maps CoS values 4 and 5 to ingress queue 1 and to threshold ID 2 with a drop
threshold of 70 percent:
Switch(config)# mls qos srr-queue input cos-map queue 1 threshold 1 0 1 2 3
Switch(config)# mls qos srr-queue input cos-map queue 1 threshold 2 4 5
Switch(config)# mls qos srr-queue input threshold 1 50 70
You can verify your settings by entering the show mls qos maps privileged EXEC command.
Related Commands Command Description
mls qos srr-queue input bandwidth Assigns shaped round robin (SRR) weights to an ingress
queue.
mls qos srr-queue input buffers Allocates the buffers between the ingress queues.
mls qos srr-queue input dscp-map Maps Differentiated Services Code Point (DSCP) values
to an ingress queue or maps DSCP values to a queue and
to a threshold ID.
mls qos srr-queue input priority-queue Configures the ingress priority queue and guarantees
bandwidth.
mls qos srr-queue input threshold Assigns WTD threshold percentages to an ingress queue.
show mls qos maps Displays QoS mapping information.

Cisco CATALYST 2960 Specifications

General

Manageable	Yes
Stacking	No
Model	Catalyst 2960 Series Switches
Power over Ethernet (PoE)	Available on some models (IEEE 802.3af)
VLANs	255 active VLANs
Features	QoS
Operating Temperature	32 to 113°F (0 to 45°C)
Relative Humidity	10% to 85% non-condensing
Power Consumption	Varies by model (30W to 400W)
